8.Slidethenewharddiskdrivewiththebluebracketintothedrivecageuntilitsnapsintopositionand
aligntheharddiskdrivecagepivotpinwiththeslot1intheupperdrivecage.Then,slidetheharddisk
drivecageintothechassis.Pressdownonthemetallatch2andpivottheharddiskdrivecageinto
place.Then,slidethedrivecagetothefrontoftheserveruntilitsnapsintoposition.
Note:Therearetwoarrows,oneontheupperdrivecageandoneontheharddiskdrivecage.The
arrowsarealignedwhentheharddiskdriveisinthecorrectposition.
Figure22.Installingtheprimaryharddiskdrive
32ThinkServerTS130UserGuide
