Lenovo ThinkServer TS140 70A0 User Manual

5.Movethejumperfromthestandardposition(pin1andpin2)tothemaintenanceposition(pin2and
pin3).
6.ReconnectanycablesthatweredisconnectedandreinstallthePCIcardifremoved.
7.Reinstalltheservercoverandreconnectthepowercordsfortheserverandmonitortoelectricaloutlets.
See“Completingthepartsreplacement”onpage90
.
8.TurnontheserverandtheninsertthePOSTandBIOSupdate(flashupdate)discintotheoptical
drive.Therecoverysessionbegins.Therecoverysessionwilltaketwotothreeminutes.Duringthis
time,youwillhearaseriesofbeeps.
9.Aftertherecoverysessioniscompleted,theseriesofbeepswillend,andthesystemwillautomatically
turnoff.Removethediscfromtheopticaldrivebeforethesystemcompletelyturnsoff.
10.Repeatstep1throughstep4.
11.MovetheClearCMOS/Recoveryjumperbacktothestandardposition(pin1andpin2).
12.ReconnectanycablesthatweredisconnectedandreinstallthePCIcardifremoved.
13.Reinstalltheservercoverandreconnectanycablesthatweredisconnected.
14.Turnontheservertorestarttheoperatingsystem.
UsingtheThinkServerEasyStartupprogram
ThistopicprovidesinstructionsonhowtousetheThinkServerEasyStartupprogramtosetupandconfigure
yourserver.
TheThinkServerEasyStartupprogramsimplifiestheprocessofinstallingsupportedoperatingsystemsand
devicedriversonyourserver.TheprogramworksinconjunctionwithyourWindowsorLinuxoperating
systeminstallationdisctoautomatetheprocessofinstallingtheoperatingsystemandassociateddevice
drivers.Thisprogramisprovidedwithyourserveronaself-starting(bootable)ThinkServerEasyStartupDVD.
TheuserguidefortheprogramalsoisontheDVDandcanbeaccesseddirectlyfromtheprograminterface.
IfyoudonothaveaThinkServerEasyStartupDVD,youcandownloadanISOimagefromtheLenovo
SupportWebsiteandmakeadiscbyyourself.
TodownloadtheThinkServerEasyStartupprogramimageandburnitintoadisc,dothefollowing:
1.Gotohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpagetolocatethe
ThinkServerEasyStartupprogram.
2.DownloadtheISOimagefortheThinkServerEasyStartupprogramandthereadmefile.Thereadmefile
containsimportantinformationabouttheThinkServerEasyStartupprogram.
3.Printthereadmefileandreaditcarefully.
4.UseanopticaldriveandanyDVDburningsoftwaretocreateabootablediscwiththeISOimage.
FeaturesoftheThinkServerEasyStartupprogram
ThistopicliststhefeaturesoftheThinkServerEasyStartupprogram.
TheThinkServerEasyStartupprogramhasthefollowingfeatures:
•Containedinaself-starting(bootable)DVD
•Easy-to-use,language-selectableinterface
•Integratedhelpsystemanduserguide
•Automatichardwaredetection
•Supportformultipleoperatingsystems
Chapter5.Configuringtheserver31

Lenovo ThinkServer TS140 70A0 Specifications

General

Memory Slots	4 DIMM slots
Form Factor	Tower
Chipset	Intel C226
Processor	Intel Xeon E3-1200 v3 series
Memory	Up to 32GB DDR3
Storage	Up to 4 x 3.5" or 2.5" HDD/SSD
RAID Support	RAID 0, 1, 10, 5
Network	Gigabit Ethernet
Network Controller	Intel I217LM
Expansion Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1, 1 x PCI
Power Supply	280W or 450W
Operating System Support	Windows Server, Red Hat, SUSE, VMware
