8.Toinstallanewtertiaryharddiskdrive,see“Installingthetertiaryharddiskdrive”onpage51.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage90.
Installingorremovingtheslimopticaldriveandthefourthharddiskdrive
Thistopicprovidesinstructionsonhowtoinstallorremovetheslimopticaldriveandthefourthharddisk
drive.
Note:Fora2.5-inchharddiskdriveorsolid-statedrive,installthedriveintoa3.5-inchto2.5-inchdrive
adapterfirst.See“Installingthe2.5-inchsolid-statedriveorharddiskdrive”onpage49.
Installingtheslimopticaldriveandthefourthharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage39.
Youcaninstallaslimopticaldriveandafourthharddiskdriveintotheopticaldrivebayofyourserver.
Thistopicprovidesinstructionsonhowtoinstalltheslimopticaldriveandthefourthharddiskdriveintothe
opticaldrivebay.
Toinstalltheslimopticaldriveandthefourthharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage41.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage42.
4.Installtheslimopticaldriveconversionboardintothecagefortheslimopticaldriveandthefourthhard
diskdrive.Then,installthetwoscrewstosecuretheslimopticaldriveconversionboard.
Figure25.Installingtheslimopticaldriveconversionboard
56ThinkServerTS140HardwareMaintenanceManual
