5.Slidethenewopticaldrivewiththeopticaldriveretainer1installedintothedrivebayfromthefrontof
theserveruntiltheopticaldrivesnapsintoposition.
Figure44.Installingtheopticaldrive
6.Reinstallthefrontbezel.See“Removingandreinstallingthefrontbezel”onpage42.
7.ConnectoneendofthesignalcabletotheopticaldriveandtheotherendtoanavailableSATA
connectoronthesystemboard.See“Locatingpartsonthesystemboard”onpage17
.Then,locatean
availablefive-wirepowerconnectorandconnectittotheSATAdrive.
Figure45.ConnectingaSATAopticaldrive
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage90.
InstallingorreplacinganinternalRDXdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage39.
Chapter6.Installing,removing,orreplacinghardware67
