USB tape drive
Note: Ensure that all cables are routed through the correct cable clips.
Figure 13. Cable routing for the USB tape drive
Cable
From To
1 Signal cable Signal connector on the tape drive Internal USB 3.0 connector on the system
board
2 Power cable Power connector on the tape drive Backplane 3 power connector on the system
board
