Lenz Digital plus SET-01/4 User Manual

Information SET-01 27
DIGITAL plus
FF For locomotive addresses 100-9999, only 28 and 128-throttle-
notches are available for use.
FF The locomotive decoder's speed step mode (set via CV29)
must match the LH100 number of throttle–positions (ðp.47 ).
The following correspondence between system and locomotive
decoder must be created:
System Locomotive
decoder
14 or 27 throttle-positions: 14 speed steps
28 or 128 throttle-positions: 28 speed steps
Setting the locomotive decoder to a particular speed step mode is
done in CV29 of the decoder. For details, see the
Digital plus by Lenz
®
"Information for locomotive decoders".
You must make sure that the locomotive decoder also
“understands” the programmed speed step mode. For Digital plus
decoders the following correspondence applies:
DIGITAL plus locomotive
decoder types
supported speed step
modes
NMRA- XF or XS-series
conforming decoders
14, 27, 28, 128
Other NMRA- conforming
decoders
14, 27, 28
all other DIGITAL plus decoders 14, 27
If unsure, please check in the decoder's operation manual. NMRA-
conforming Digital plus by Lenz
®
decoders can be recognized by the
following symbols on the title page of the operation manuals:
