Lenz Digital plus SET-01/4 User Manual

Information SET-01 79
DIGITAL plus
16.2.1 Connecting additional LV101s
Connect terminals C,D (and optionally E) of the first LV101 with
terminals C,D and E of the next LV101. Power each LV101 with its
own transformer.
Isolate both rails of the track at the junction of the single supply
areas and make sure the polarity is the same.
If you are operating locomotives with offset pickups (common in HO
scale brass steam locomotives), Connect terminal C together
between all LV101s. This will provide the necessary common
connection to operate these locomotives.
You will find further information in the operating manual of the
additional LV101.

Lenz Digital plus SET-01/4 Specifications

General

Brand	Lenz
Model	Digital plus SET-01/4
Category	Control Unit
Language	English
