Parameter setting
Code Input Description
Input according to motor nameplate
C083 xxx A Rated field current
C084 xxx ms Armature-time constant
C088 xxx A Rated motor current
C090 xxx V Rated motor voltage
Enter controller configuration
C000 -2- Extended code set
C005 -10- Speed control with armature-voltage feedback
Input of current limits
C022, C023 xxx A Maximum motor current
Adjustment of speed controller
C011 xxxx rpm Enter max. speed
C025 -5- Select armature voltage
C232 xx % V
Arated
I
¼
R - Set compensation
C029 n
act
Adjust speed
Application parameters
C070 V
pn
At high inertia, adapt n - controller gain V
pn
Save parameter
C003 Save parameter set
Note!
( With armature-voltage feedback, the control terminals are still volt-free!
( Mains disconnection only when no current is applied!
