Code table
10
Function library
10.20
L
10.20-31
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0415
v
Free configuration
of digital outputs
Output of digital signals to terminals
^ 10.13-6
1 Relay output K1
(RELAY)
25 TRIP fault message (DCTRL1-TRIP) A selection under C0008 will be copied
to C0415/1. A change of C0415/1 sets
C0008 = 255!
2 Digital output
X3/A1 (DIGOUT1)
16 Ready for operation (DCTRL1-RDY) A selection under C0117 will be cop ied
to C0415/2. A change of C0415/2 sets
C0117 = 255!
3(A) Digital output
X3/A2 (DIGOUT2)
255 Not assigned (FIXED-FREE)
