Lenze 8200 vector User Manual

Selection
Required mains filters or mains chokes
12
Network of several drives
12.5
12.5.2
L
12.5-2
EDS82EV903-1.0-11/2002
12.5.2 Required mains filters or mains chokes
Prescribed mains chokes for supply terminals in the network operation:
Controller/supply unit/feedback unit Mains choke
Type Rated mains
current [A]
Rated curren t
[A]
Inductance
[mH]
Order no.
9341 12.0 12.0 1,20 EZN3A0120H012
9342 24.0 24.0 0.88 EZN3A0088H024
9343 45.0 45.0 0.55 EZN3A0055H045
9364 74.0 85.0 0.38 ELN3-0038H085
9365 148.0 170.0 0.17 ELN3-0017H170
9321, 8241 4.2 4.5 9.00 EZN3A0900H004
E82EV551K4B, E82EV751K4B 2.3 3.0 15.00 EZN3A 1500H003
9322, 8242, 8211 3.3 4.5 9.00 EZN3A0900H004
8212 3.5 4.5 9.00 EZN3A0900H004
9323, 8243 7.0 7.0 5.00 EZN3A0500H007
E82EV152K4B, E82EV222K4B 5.8 6.1 6.80 E82ZL22234B
8213, 8214 6.5 7.0 5.00 EZN3A0500H007
9324, 8244 7.6 9.0 4.00 EZN3A0400H009
E82EVK302K4B 9.2 13.0 3.00 EZN3A0300H013
8215, E82EV402K4B 10.0 13.0 3.00 EZN3A0300H013
9325, 8245, 8216 12.0 13.0 3.00 EZN3A0300H013
E82EV552K4B 13.6 13.0 3.00 EZN3A0300H013
E82EV752K4B 17.6 24.0 1.50 ELN3-0150H024
9326, 8246, 8217, 8218,
E82EV113K4B
21.8 24.0 1.50 EZN3A0150H024
9327, 8221, E82EV153K4B 45.0 45.0 0.75 ELN3-0075H045
9328, 8222, E82EV223K4B 50.0 55.0 0.88 ELN3-0088H055
9329, 8223, E82EV303K4B 55.2 60.0 0.55 EZN3A 0055H060
9330, 8224, E82EV453K4B 91.7 105.0 0.27 ELN3-0027H105
9331, 8225, E82EV553K4B 103.8 105.0 0.27 ELN3-0027H105
9332, 9333, 8226, 8227,
E82EV753K4B, E82EV903K4B
161.7 170.0 0.17 ELN3-0017H170
