Function library
Configuration of analog and digital setpoints and actual values
7−44
L
EDB82MV752 EN 5.2
Operation with application I/O
The signal NSET1−JOG1/3/5 must be combined with a digital input signal under C0410/1.
The signal NSET1−JOG2/3/6/7 must be combined with a digital input signal under C0410/2.
The signal NSET1−JOG4/5/6/7 must be combined with a digital input signal under C0410/33.
Active setpoint Level at
NSET1−JOG1/3/5/7 NSET1−JOG2/3/6/7 NSET1−JOG4/5/6/7
other setpoint source LOW LOW LOW
JOG 1 HIGH LOW LOW
JOG 2 LOW HIGH LOW
JOG 3 HIGH HIGH LOW
JOG 4 LOW LOW HIGH
JOG 5 HIGH LOW HIGH
JOG 6 LOW HIGH HIGH
JOG 7 HIGH HIGH HIGH
Influence on other setpoints
The maximum output frequency (C0011) also limits the fixed setpoints (JOG).
The minimum output frequency (C0010) does not limit the fixed setpoints (JOG).
Fixed setpoints (JOG) have priority over the analog setpoint 1 (NSET1−N1) and over the analog
setpoint 2 (NSET1−N2).
The additional setpoint (PCTRL1−NADD) is added to the fixed setpoints.
Tip
The display of the parameter can be related to a process variable. (
7−86 )
