7.6.3 Digital setpoints via frequency input
Description
It is possible to configure the digital inputs E1 and E2 of the standard I/O or application I/O as
frequency input. This enables you to select a digital frequency as setpoint or actual value:
 For operation with standard I/O
– single−tracked: 0 ... 10 kHz at X3/E1
– two−tracked: 0 ... 1 kHz at X3/E1 and X3/E2
 For operation with application I/O
– single−tracked: 0 ... 100 kHz at X3/E1
– two−tracked: 0 ...100 kHz at X3/E1 and X3/E2
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0425*

Configuration
frequency input
single track X3/E1
(DFIN1)
2
f
r
f
min
t f
max
 f
r
= Normalisation frequency
–f
r
corresponds to C0011
 f
min
= Resolution
 t = Scanning rate
– The lower the scanning rate the
higher the dynamic response.
 f
max
= Maximum frequency which can
be processed independently of C0425
– Set C0425 that the frequency coming
from the encoder is lower than f
max
 Activate frequency input with
C0410/24 = 1
 Adjust frequency input under C0426 and
C0427
 7−39
0 100 Hz 1/200 1 s 300 Hz
1 1 kHz 1/200 100 msec 3 kHz
2 10 kHz 1/200 10 msec 10 kHz
3 10 kHz 1/1000 50 msec 10 kHz
4 10 kHz 1/10000 500 ms 10 kHz
5 (A) 102.4 kHz 1/400 2 msec 102.4 kHz
6 (A) 102.4 kHz 1/1000 5 msec 102.4 kHz
7 (A) 102.4 kHz 1/2000 10 msec 102.4 kHz
Configuration
frequency input two
tracks X3/E1, X3/E2
(DFIN1)
10 100 Hz 1/200 1 s 300 Hz
11 1 kHz 1/200 100 msec 3 kHz
12 (A) 10 kHz 1/200 10 msec 10 kHz
13 (A) 10 kHz 1/1000 50 msec 10 kHz
14 (A) 10 kHz 1/10000 500 ms 10 kHz
15 (A) 102.4 kHz 1/400 2 msec 102.4 kHz
16 (A) 102.4 kHz 1/1000 5 msec 102.4 kHz
17 (A) 102.4 kHz 1/2000 10 msec 102.4 kHz
C0426* Gain frequency
input X3/E1, X3/E2
(A) (DFIN1−GAIN)
100 −1500.0 {0.1 %} 1500.0
C0426 
f
N
 p
z  C0011
 100%
 f
r
= Normalisation frequency from
C0425
 p = Number of pole pairs of the motor
 z = Number of increments per revolution
of the encoder
 C0011 = Maximum output frequency
(corresponds to maximum process
speed of the motor)
C0427* Offset frequency
input X3/E1, X3/E2
(A) (DFIN1−OFFSET)
0.0 −100.0 {0.1 %} 100.0
