Technical data
General data/operating conditions
3−1
L EDB82MV752 EN 5.2
3 Technical data
3.1 General data/operating conditions
Standards and operating conditions
Conformity CE Low−Voltage Directive (73/23/EEC)
EMC Directive (93/68/EEC)
Approvals UL 508C Underwriter Laboratories (File−No. E132659)
Power Conversion Equipment
Vibration resistance Acceleration resistant up to 2g (Germanischer Lloyd, general conditions)
Climatic conditions
Storage IEC/EN 60721−3−1
1K3 (−25 °C...+60 °C) < 6 months
1K3 (−25 °C...+40 °C) > 6 months
> 2 years: form the DC bus capacitors
Transport IEC/EN 60721−3−2 2K3 (−25 °C...+70 °C)
Operation IEC/EN 60721−3−3 3K3 (−20 °C...+60 °C)
At temperatures above +40 °C, the rated output current should be derated by
2.5 %/ °C
Permissible installation height 0 ... 4000 m amsl
The rated output current should be derated by 5 %/1000 m above 1000 m amsl
Degree of pollution VDE 0110 part 2 degree of pollution 2
Mounting positions All mounting positions and mounting alignments are permitted
Free space
above 100 mm
to the sides 100 mm
DC−bus operation not possible
Mechanical design
Housing Carrier housing: glass−fiber reinforced plastic, heatsink: die−cast aluminium
Screwed
connections
E82MV251K2B, E82MV371K2B 4 x M20/ 2 x M16 (thread length 10 mm, without counternut)
E82MV551K4B, E82MV751K4B 2 x M25/ 4 x M16 (thread length 10 mm, without counternut)
1 x M20 for motor cable in case of wall mounting (EMC cable gland, thread length 10 mm, with counternut)
E82MV152K4B, E82MV222K4B 2 x M25/1 x M20/4 x M16 (thread length 10 mm, without counternut)
1 x M20 for motor cable in case of wall mounting (EMC cable gland, thread length 10 mm, with counternut)
E82MV302K4B, E82MV402K4B,
E82MV552K4B, E82MV752K4B
3 x M25/4 x M16 (thread length 10 mm, without counternut)
