3.2 Rated data at a mains voltage of 230 V
3.2.1 Operation with rated power (normal operation)
Typical motor power
Three−phase asynchronous motor
(4−pole)
P
N
[kW] 0.25 0.37
P
N
[hp] 0.34 0.5
8200 motec Type E82MV251_2B E82MV371_2B
Mains voltage U
mains
[V] 1/N/PE AC 180 V − 0 % ... 264 V + 0 % ; 45 Hz − 0 % ... 65 Hz + 0 %
Data for operation at 1/N/PE AC 230 V
Rated mains current I
mains
[A] 3.4 5.0
Rated output current at
switching frequency
2 kHz
I
N24
[A]
2)
2.0 2.9
4 kHz
8 kHz I
N8
[A] 1.7 2.4
16 kHz I
N16
[A] 1.1 1.6
Max. permissible output
current for 60 s at
switching frequency
1)
2 kHz
I
max24
[A] 2.5 3.6
4 kHz
8 kHz I
max8
[A] 2.5 3.6
16 kHz I
max16
[A] 1.6 1.4
Output voltage U
M
[V] 3~ 0 ... U
mains
/ 0 ... 650 Hz
Power loss (operation with I
N8
) P
v
[W] 30 40
Dimensions L x W x H [mm] 190 x 138 x 100
Weight m [kg] 1.8 1.8
Bold print = data for operation at a switching frequency of 8 kHz (Lenze setting)
1)
Currents for periodic load change: 1 min overcurrent time with I
max
and 2 min base load time with 75 % I
Nx
2)
Under different operating conditions possible for some types: Operation with increased rated output current with the same load change
cycle ( 3−6)
Fuses and cable cross−sections
8200 motec
Normal operation
Installation acc. to EN 60204−1 Installation acc. to UL
1)
Type System Fuse Circuit breaker L1, L2, L3, PE Fuse L1, L2, L3, PE FI
[kW] [mm
2
] [AWG]
E82MV251_2B 0.25
1/N/PE AC
180 ... 264 V;
45 ... 65 Hz
M10 A C10 A 1.5 10 A 16
 30 mA
2)
E82MV371_2B 0.37 M10 A C10 A 1.5 10 A 16
1)
Only use UL−approved cables, fuses, and fuse holders.
UL fuse: voltage 240 V, tripping characteristic "H", "K5" or "CC"
2)
Pulse current sensitive or universal−current sensitive earth−leakage circuit breaker
Observe national and regional regulations
