Lenze E82MV152_4B

Function library
Process controller, current limitation controller
7−54
L
EDB82MV752 EN 5.2
Process controller setpoint = C0181
C0145 = 1
Process controller setpoint = Value under C0181.
 Applications are e.g. dancer controls, pressure controls and flow rate controls
 Activate the automatic DC−injection brake (auto DCB) with C0019 = 0 or C0106 = 0
 C0181 is the same in all parameter sets.
C0145 = 2
Process controller setpoint = Freely configured signal via C0412/4.
 The process controller setpoint (PCTRL1−SET1) must be linked with an analog input signal
under C0412/4.
 Use C0138 to display the current process controller setpoint.
 The setpoint acts directly on the process controller.
) Note!
If you do not link an analog input signal with the process controller setpoint under
C0412/4, the process controller setpoint can be directly selected under C0138.
7.8.3 Actual value selection for the process controller
Description
The actual value is the process feedback signal (e.g. from a pressure encoder or a speed encoder).
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0051* Output frequency
with slip
compensation
(MCTRL1−NOUT
+SLIP) or
act. process
controller value
(PCTRL1−ACT)
−650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
Operation without process controller
(C0238 = 2):
 Display only: Output frequency with slip
compensation (MCTRL1−NOUT+SLIP)
Operation with process controller
(C0238 = 0, 1):
 Selection, if C0412/5 = FIXED−FREE (not
assigned)
 Display if C0412/5 is linked with a signal
source
 7−54
Activation
The actual process controller value (PCTRL1−ACT) must be linked with an analog input signal under
C0412/5.
Use C0051 to display the current actual process controller value.
) Note!
If you do not link an analog input signal with the actual process controller value
under C0412/5, the actual process controller value can be directly selected under
C0051.
