Parameter setting
With keypad
6−5
L
EDB82MV752 EN 5.2
6.2.4 Changing and saving parameters using the keypad
Tip!
After every mains switching, the user menu is active. In order to be able to call up all codes,
you have to change to the all menu.
Action Key
sequence
Result Comment Example
1. Attach keypad

xx.xx
Hz
Function  is active. The first code in the user menu (C0517/1, Lenze
setting: C0050 = output frequency) is displayed.
2.
If required,
change to the
menu "ALL"

 Change to function bar 2
3.


4.

all Select menu "ALL" (list of all codes)
5.

 Confirm selection and change to function bar 1
6. Inhibit
controller
 
Only necessary if you alter C0002, C0148, C0174, and/or C0469
7.
Set
parameters
 
C0412, assign subcode 3 to
value 3.
8.
 XXXX
Select code
0412
9.
 (
001
For codes without subcodes: automatic skip to 
10.
 xxx
Select subcode
003
11.
 
12.
 XXXXX
Set parameters 3
13.
 STOre
Confirm entry if is blinking

Confirm entry if is not blinking; is inactive
14. Restart "loop" at 7. again, in order to set further parameters
6.2.5 Change parameter set
Tip!
The keypad can only be used to change to parameter sets in order to change the parameters. Use
digital signals to activate a parameter set for operation (configuration with C0410)!
The  function shows the parameter set active in the operation at this moment.
Action Key
sequence
Result Comment Example
1.
Select
function

 Change to function bar 2
Select parameter set 2.
2.


3.
Select
parameter set

1 ... 4 Select parameter set to be changed
2
4.

 Confirm selection and change to function bar 1
5. Set
parameters
As described in chapter 6.2.4
