Function library
Individual grouping of drive parameters − The menu USEr
7−95
L EDB82MV752 EN 5.2
7.16 Individual summary of drive parameters in the user menu
Description
Fast access to 10 codes
Individual combination of 10 codes most important for your application.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0517*
User menu
After mains switching or when using the
function the code from C0517/1
will be displayed.
In Lenze setting, the user menu contains
the most important codes for starting−up
the control mode "V/f characteristic
control with linear characteristic"
When the password protection is
activated, only the codes entered under
C0517 are freely accessible.
Enter the required code numbers in the
subcodes.
Codes, which are only active when
being used together with an
A
lication−I/O
cannot be entered!
7−95
1 Memory 1 50 C0050 Output frequency (MCTRL1−NOUT)
2 Memory 2 34 C0034 Analog setpoint selection range
3 Memory 3 7 C0007 Fixed configuration − digital input signals
4 Memory 4 10 C0010 Minimum output frequency
5 Memory 5 11 C0011 Maximum output frequency
6 Memory 6 12 C0012 Acceleration time main setpoint
7 Memory 7 13 C0013 Deceleration time main setpoint
8 Memory 8 15 C0015 V/f rated frequency
9 Memory 9 16 C0016 U
min
boost
10 Memory 10 2 C0002 Parameter set transfer
User menu adaptation
Enter the required code number or subcode number into the subcodes under C0517.
) Note!
Use the user menu to select "tailored" codes for your application to be used by
your personnel if the password protection is activated additionally. Your personnel
can only change codes listed in the user menu.
Example: Select speed via keypad
The personnel operating a transportation system shall be able to change the speed of the conveyor
using the keypad. The speed is set and indicated in "rpm":
User menu configuration
1. Assign C0140 to memory 1 of the user menu (C0517/1 = 140)
2. Delete all other entries from the user menu (C0517/2 ... C0517/10 = 0)
3. Convert the value indicated under C0140 into "rpm" using C0500/C0501 ( 7−86)
4. Activate the password protection (C0094 > 0)
5. The current conveyor speed will be indicated after the keypad has been attached or power
on.
6. Use to activate the function and to change the speed during operation using the
keys. The speed set last will be stored when the mains is switched off.
