Commissioning
Setting of the feedback system for position and speed control
TTL/SinCos encoder as position and speed encoder
6
116
EDBCSXM064 EN 11.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
[C0427]
Enc. signal
0
Function of the master frequency
input signals on X8 (DFIN)
113
121
0
2−phase
1
A: speed
B: direction
2
A or B: speed or direction
[C0491]
X8 in/out
0
Function of X8
113
121
0
X8 is input
1
X8 is output
115
117
