Commissioning
Following error monitoring (C3030, C3031)
6
171
EDBCSXM064 EN 11.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C3032
FollErr1reac
2
First reaction when following
error limit has been reached
170
0
TRIP
1
Message
2
Warning
3
Off
4
FAIL−QSP
C3033
FollErr2reac
4
Second reaction when following
error limit has been reached
170
0
TRIP
1
Message
2
Warning
3
Off
4
FAIL−QSP
170
