Appendix
Code table
12

281
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0027 Gain for relative analog signals
(AIN)
1 FCODE(gain) 100,0 −199,99 {0.01 %} 199,99 FCODE_nC27_1_a
2 FCODE(gain) 100,0 FCODE_nC27_2_a
C0030 DFOUT const 3
Constant for the digital
frequency signal DFOUT_nOut_v
on X8 in increments per
revolution
 113
 121
0 256 incr./rev
1 512 incr./rev
2 1024 incr./rev
3 2048 incr./rev
4 4096 incr./rev
5 8192 incr./rev
6 16384 incr./rev
C0032 FCODE
Gearbox
1
Freely configurable code for
gearbox factor ?
(FCODE_nC32_a)
−32767 {1} 32767
C0034 Mst current 0
Master voltage/master current
on analog input (AIN1_nIn_a)
0 −10 ... + 10 V Master voltage
1 +4 ... +20 mA
Master current
2 −20 ... +20 mA
C0037 Set−value rpm 0
Setpoint selection in rpm
(FCODE_nC37_a)
−16000 {1 rpm} 16000
C0040 Ctrl enable 1
Controller enable / controller
inhibit (CINH)
l Writing: Controls the
controller inhibit
l Reading: Reads the status of
the controller inhibit
0 Controller inhibited
1 Controller enabled
C0042 DIS: QSP
Quick stop status (QSP)
Only display
 173
0 QSP not active
1 QSP active
C0043 Trip reset 0
Reset active fault message
(TRIP−RESET)
 278
0 Reset fault message (TRIP−RESET) / no
fault
1 Active fault message
C0050 MCTRL−NSET2
Speed setpoint on speed
controller input
(MCTRL_nNSetIn_a)
Read only
−100,00 {0.01 %} 100.00
C0051 MCTRL−NACT
Actual speed (MCTRL_nNAct_a)
Read only
−30000 {1 rpm} 30000
