Appendix
Code table
12
284
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0076 Tn currCTRL 5.0
Reset time of current controller
(T
ni
)
178
0.01 {0.01 ms} 200.00
C0077 Vp fieldCTRL 5.0
Field controller gain (V
pF
)
185
0.00 {0.01} 63.99
C0078 Tn fieldCTRL 20.0
Field controller reset time (T
nF
)
185
1.0 {0.5 ms} 6000.0
C0079 DIS:Lh
Mutual inductance of the
asynchronous motor
Read only
0.0 {0.1 mH} 3276.7
[C0080] Res pole no. 1
Number of pole pairs of resolver
1 {1} 10
[C0081] Mot power 3.20
Rated motor power according to
nameplate
0.01 {0.01 kW} 500.00
[C0082] DIS:Rr
Rotor resistance of the
asynchronous motor
Read only
0.000 {0.001 W} 32.767
C0083 DIS:Tr
Rotor time constant of the
asynchronous motor
Read only
0.00 {0.01 ms} 327.67
[C0084] Mot Rs 1.10
Stator resistance of the motor
The upper limit is
device−dependent.
0.00 {0.01 W} 95.44 ECSxS/P/M/A004
47.72 ECSxS/P/M/A008
23.86 ECSxS/P/M/A016
11.93 ECSxS/P/M/A032
7.95 ECSxS/P/M/A048
5.96 ECSxS/P/M/A064
[C0085] Mot Ls 5.30
Leakage inductance of the motor
0.00 {0.01 mH} 200.00
[C0087] Mot speed 3700
Rated motor speed
300 {1 rpm} 16000
[C0088] Mot current 7.0
Rated motor current
0.5 {0.1 A} 500.0
[C0089] Mot
frequency
185
Rated motor frequency
10 {1 Hz} 1000
[C0090] Mot voltage 325
Rated motor voltage
50 {1 V} 500
[C0091] Mot cos phi 1.0
cos j of the asynchronous motor
0.50 {0.01} 1.00
C0092 DIS:Isdeff
Magnetising current of the
asynchronous motor
Read only
0.00 {0.01 A} 327,67
