Appendix
Code table
12

310
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0866 Analog process data input words
(decimal) for CAN bus interface
X4
100.00% = 16384
Read only
 340
1 CAN IN words −199.99 {0.01 %} 199.99 CAN1_IN word 1
2 CAN IN words CAN1_IN word 2
3 CAN IN words CAN1_IN word 3
4 CAN IN words CAN2_IN word 1
5 CAN IN words CAN2_IN word 2
6 CAN IN words CAN2_IN word 3
7 CAN IN words CAN2_IN word 4
8 CAN IN words CAN3_IN word 1
9 CAN IN words CAN3_IN word 2
10 CAN IN words CAN3_IN word 3
11 CAN IN words CAN3_IN word 4
C0867 32−bit phase information for
CAN bus interface X4
Read only
1 CAN IN phi −2147483648 {1} 2147483647 CAN1_IN
2 CAN IN phi CAN2_IN
3 CAN IN phi CAN3_IN
C0868 DIS:OUTx.Wx Analog process data output
words (decimal) for CAN bus
interface X4
100.00% = 16384
Read only
1 CAN OUT
words
−32768 {1 %} 32768 CAN1_OUT word 1
2 CAN OUT
words
CAN1_OUT word 2
3 CAN OUT
words
CAN1_OUT word 3
4 CAN OUT
words
CAN2_OUT word 1
5 CAN OUT
words
CAN2_OUT word 2
6 CAN OUT
words
CAN2_OUT word 3
7 CAN OUT
words
CAN2_OUT word 4
8 CAN OUT
words
CAN3_OUT word 1
9 CAN OUT
words
CAN3_OUT word 2
10 CAN OUT
words
CAN3_OUT word 3
11 CAN OUT
words
CAN3_OUT word 4
