Rev. 03 - 07/2015 - Cod. 1501151 - Instruction manual for vacuum chamber packaging machines Mod. C254-C308-C312-C412-C420

Openthecover.
Removethesiliconeproleontheoffsetbar
.
Cleantheseatwithaclothsoakedinalcohol.
Put ina new siliconeprole, pushingitin a
uniformmanner. Donot stretchthe silicone
prolewhenttingitin.

Toaccessthepowerboard,followtheproceduredescribedinchap.11.2.
Unscrewtheprotectivelidfromthepowerboard.
Locatethepowerboardandundothecartridgefuseholder
A
.Inthecaseofmachineswiththree-phase
powersupply,openthecontrolboxandtakeoutalsothemainfuseholderofthepowersupplycircuit.
Removethefuseanduseatestertotesttheirconditionandreplaceifnecessary.
Putthecartridgebackinthefuseholderandfastenitwiththescrewdriver.
Attachtheprotectivelid,takingcarenottocompressthehosesandcablesconnectedtothepowerboard
.
Closethemachinefollowingchap.11.2.
