Rev. 03 - 07/2015 - Cod. 1501151 - Instruction manual for vacuum chamber packaging machines Mod. C254-C308-C312-C412-C420

Removetherearpanel,looseningthescrewswitha
Phillipsheadscrewdriver.
Raisethelid.
Removetheelasticringfromthepistonattachment
pin.
Pullthepinandtiltthelidback,restingitonastable
support.
Unscrewthegasspring

fromtheslidingpin
C
by
graspingthetopandturningitcounterclockwise.
