LESER Global Standard
Assembly instructions for type 526 API
LGS 4104
Page 11/45
disclosure cat.:
II
proofread:
SSt
published date:
06/14/18
effect. date:
05/18
author:
Nieh
released by:
KUW
replaces:
initial
status:
Published
resp. depart.:
IE
date of release:
06/14/18
revision No.:
2
doc. type:
LGS
change rep. No.:
NA
retention period:
10
protected
Illustration
Description
Aids / Tools
Figure 9.4.2-5
Secure the nut by hitting it
with a centre punch
Centre punch
Hammer
Figure 9.4.2-6
Emboss the marking for the
O-ring material according to
WI 3308-08 .
Punch
numbers
Hammer
