9.14.2 O-ring damper H4
Illustration
Description
Aids / Tools
Figure 9.14.2-1
Individual parts of the O-ring damper
H4
Figure 9.14.2-2
Fasten the O-ring damper on the
spindle with a steel pin and retaining
clip.
Then assemble the H4 lever cover as
described in 12.43.
Figure 9.14.2-3
