LEVC VN5 2021 - Longitudinal CoG Position

General Information
1
S023074 PA1
2020-05-12
17
Measurements Required Measurements Taken
1st 2nd 3rd
Rear Axle Weight m'
H
kg
Height (Lift) H mm
Inclination Angle * α deg
Centre of Gravity Height ** Z mm
Values (Horizontal)
Centre of Gravity (CoG) height (from the ground) Z
Wheelbase WB
Front axle weight m
V
Rear axle weight m
H
Total vehicle weight m
G
Radius of the tyre r
tyre
Values (Inclined)
Centre of Gravity (CoG) height (from the vehicle axle centre line) Z
SP
Front axle weight m'
V
Rear axle weight m'
H
Total vehicle weight m'
G
Height (lift) H
Angle of incline α
