3
Electrical
50
PA1
2020-05-12
S023074
WAM Wide Angle Vision Module
WMM Wiper Motor Module
Charging System
General Information
WARNING
Do not make changes to the High Voltage (HV) system.
WARNING
Do not try to connect electrical equipment to the High Voltage (HV) system.
WARNING
Use the high voltage battery charging cable supplied. Use of a high voltage
battery charging cable not recommended by LEVC may result in death, serious
injury or damage to the vehicle. Refer to a LEVC Approved Dealer for details of
the approved cables.
CAUTION
If the 12V battery is discharged:
– Do not use 'Fast' or 'Boost' mode on charging equipment.
– Do not connect another vehicle to do a 'Jump start'.
– Do not connect a battery charger directly to the 12V battery terminals in the
vehicle.
– Refer to the operators manual for the correct procedure.
The vehicle does not have a belt driven alternator. Refer to Accessory Drive,
page 75 for
more information.
The vehicle has a 12V battery and a High Voltage (HV) battery. If the the 12V battery is
discharged it is not possible to start the vehicle.
For information on charging the HV battery and the 12V battery refer to the operators manual.
Transport Mode
The vehicle is supplied in transport mode. Transport mode prevents the operation of some 12V
systems, so that less electrical power is used when the vehicle is moved or stored. To stop
transport mode temporarily, put the vehicle in drive mode. The vehicle will go back into transport
mode two minutes after it is switched off.
