Electrical
3
S023074 PA1
2020-05-12
51
CAUTION
The vehicle will go back into transport mode two minutes after it is switched off. Do
not lock the vehicle during this time period. The central locking is disabled when the
vehicle is in transport mode and you will be locked out of the vehicle. If you are
locked out refer to Central Locking and Remote Key-less Entry,
page 57.
To pause transport mode for two minutes press the hazard light switch twice quickly.
It is necessary to use the VIDA diagnostic tool to stop transport mode. You must put the vehicle
in the normal mode before it is delivered to the operator.
Drive Modes
The engine will not run in some conditions or drive modes. If you select 'SAVE' mode the engine
will run if an electrical load starts to drain the High Voltage (HV) battery. Refer to the operators
manual for more information about drive modes.
Electrical Conversions
WARNING
Do not install voltage boosters or equipment to increase the electrical output
of the vehicle.
If the conversion requires the installation of additional electrical equipment you must make sure:
– The conversion obeys local regulations.
– The operators use of the vehicles features is not prevented by components installed in the
conversion.
– Components installed in the conversion must not prevent access to areas of the vehicle that
require maintenance.
– Additional circuits are not installed next to the wiring harness for the engine management
system. This will prevent electronic interference.
Installation of Electric Motors
If you install an electric motor in the conversion you must:
– Only install motors with electrical suppression. To prevent electrical interference with the
vehicle.
– Control the motor with a relay.
– Use the correct size of wire.
– Install the correct size fuse in the circuit.
The electrical components used must be rated a minimum of three times the current rating of
the motor. This will prevent damage caused by high in rush current when the motor is switched
on.
Circuit Diagrams
For circuit diagrams and additional information about the electrical system refer to the workshop
manual.
