Electrical
3
S023074 PA1
2020-05-12
43
Wiring harnesses must be a minimum of 25 mm from sharp edges and 35 mm from moving
parts. If the clearance is not possible install protective sleeves to protect the wiring.
Do not use connectors that use springs or screws to secure the connections. Vibration causes
the terminals to loosen.
Crimp terminals must have two retaining features to attach to the wire and the insulation. This
prevents strain on the wire.
Ratchet crimping pliers are recommended to apply the correct force when you install terminals.
All connections must be crimped. Only solder connections to reduce impedance.
If you install wiring through holes in SMC panels or aluminium extrusions, install grommets or
edge protection to prevent damage to the wiring.
All wiring must have secondary method of protection. Install tape, conduit or sleeving to protect
the wiring harness.
Electrical Installation
Do not cut into the vehicles wiring harness. If you cut into the wiring harness there there is a risk
defective connections or fire caused by electrical overload.
All connections to the vehicles wiring harness must be insulated. Connections in the engine bay
or under the vehicle must be water resistant.
Additional wiring installed in the conversion must use the correct specification of wire for the
electrical load.
Additional electrical equipment must have additional connections to ground.
The converter must produce a wiring diagram and instructions for the components installed in
the conversion. This information must be added to the operators information to aid fault
diagnosis, or the installation of other equipment at a later date.
NOTE
For additional information or technical support contact Aftersales@LEVC.com.
Unused Connectors
The vehicle can have unused connectors in the wiring harness. You must only connect to the
connectors specified in this document. Refer to After Market In-line Connector,
page 67 for
more information.
Prevent Squeaks and Rattles
The wiring harness must be supported and secured every 300 mm. Electrical connectors must
be attached to the vehicle to prevent unwanted noises. Use tape and foam secure or insulate
the wiring to prevent unwanted noises.
