ISO Conductor Size mm
2
CSA Maximum Resistance
mOhm/m
Minimum Resistance
mOhm/m
2.5 7.60 6.99
3 6.15 5.66
4 4.71 4.33
5 3.94 3.62
6 3.14 2.89
8 2.38 2.19
10 1.82 1.68
12 1.52 1.40
16 1.16 1.07
20 0.955 0.870
25 0.743 0.688
30 0.647 0.595
35 0.527 0.489
40 0.473 0.435
50 0.368 0.343
60 0.315 0.290
70 0.259 0.243
95 0.196 0.185
120 0.153 0.146
Electromagnetic Interference
WARNING
Do not install wiring near the vehicles wiring harness for the ABS and traction
control systems. Electromagnetic interference can cause these systems to
malfunction. LEVC are not responsible for the effects of electromagnetic
interference caused my the converters electrical installation.
To prevent electromagnetic interference, install additional wiring:
– 10 mm from static components (unless attached to the component).
– 250 mm from the exhaust system.
– 30 mm from components that rotate.
Wiring Through Sheet materials
WARNING
You must install grommets to protect the wiring where it goes through panels.
