Chassis
4
S023074 PA1
2020-05-12
71
Tyre Specification
Description Data
Width 215
Aspect Ratio 60
Construction Radial
Diameter 17
Load Index 107
Speed Index T
The standard tyres are marked 215/60R17C. The C shows the tyre is applicable for comercial
use. Do not install tyres that are not applicable for comercial use.
Wheel Clearance
Components installed in the conversion must not obstruct the movement of the wheels. Do a
check to make sure the steering and suspension move correctly, and tyres do not rub.
Tyre Pressure Monitoring System (TPMS)
The vehicle is equipped with TPMS. The system uses the wheel speed sensors to check for
changes in the diameter of the tyres. No sensors are attached to the wheels.
If the TPMS warning light is shown on the drivers display refer to the operators handbook.
Spare Wheel / Tyre Sealant Kit
A spare wheel is optional. If you relocate the spare wheel or sealant kit it must be secure and
accessible to the operator.
If you relocate this equipment make sure it is labeled so the operator can find it.
Painting Road Wheels
CAUTION
Do not paint the mating faces of the wheel that touch the brake disc, wheel spacer
(rear) or the wheel bolts. This can cause the wheels to come loose. Always mask the
surfaces shown before you paint the wheels.
