4.3.7 Application (Excluding Compact IP Dome)
The IP Camera (Box Camera and Vandal Proof Dome) equips one alarm input
and one relay output for cooperating with alarm system to catch events’ images.
Refer to alarm pin definition below to connect alarm devices to the IP Camera if
needed. The alarm configuration page is also shown below.
Alarm Pin Definition
