Video Format
The IP Camera provides various video dual streaming formats like the following:
• MJPEG + H.264
• MJPEG + MPEG-4
• MJPEG + BNC
• H.264 + H.264
• H264 + BNC
Resolution for MJPEG & H.264 format includes:
• 1280 x 960 (CCD) / 1280 x 1024 (CMOS) (12.5/15fps)
• HD 720p: 1280 × 720 (25/30fps)
• D1: 720 × 480 (25/30fps)
• VGA: 640 × 480 (25/30fps)
• QVGA: 320 × 240 (25/30fps)
• CIF: 352 × 240 (25/30fps)
• QCIF: 176 × 144 (25/30fps)
Click “Save” to confirm the Video Format setting.
Text Overlay Settings
Users can select the items to display data including date/time/text on the live
video pane. The maximum length of the string is 20 alphanumeric characters
Click “Save” to confirm the Text Overlay setting.
Video Rotate Type
Users can change video display type if necessary. Selectable video rotate types
include Normal, Flip, Mirror and 180 degree. Differences among these types are
illustrated as below.
Suppose the displayed image of IP camera is shown as the figure below.
