Appendix A
Specifications
Wireless Access Point
Hardware Specifications
SDRAM
16 Mbytes
Flash ROM
4 Mbytes
LAN port
1 x Auto-MDIX RJ 45 for 10/100Mbps Ethernet
Operating temperature
0 C to 40 C
Storage temperature
-20 C to 70 C
Power Adapter
12VDC 1A External
Dimensions
125mm(W) * 123mm(D) * 31mm(H)
Wireless Specifications
Standard
Network Standard IEEE 802.11n 2.0, IEEE 802.11b and
IEEE 802.11g compliance
Transfer Rate
IEEE802.11b
11M/5.5M/2M/1M
IEEE802.11g
54M/48M/36M/24M/18M/12M/11M/9M/6M
IEEE802.11n 2.0
300M/270M/243M/240M/216M/180M/162M/120M/108
Mbps in 40Mhz mode
145M/130M/117M/104M/78Mbps in 20Mhz mode
Bandwidth
IEEE802.11b: Over 5Mbps
IEEE802.11g: Over 20Mbps
IEEE802.11n 2.0: Over 60Mbps (20Mhz mode ) /100
Mbps (40Mhz mode)
Channels
2.4GHz ~ 2.485GHz / 1~13 channels
Transmission mode
IEEE802.11b: CCK (11 Mbps, 5.5 Mbps), DQPSK (2
Mbps), DBPSK (1 Mbps)
IEEE802.11g: OFDM
IEEE802.11n 2.0: OFDM
Transmit Range
Indoor 200~280m/outdoor 450~600m
Modulation
IEEE802.11b DBPSK / DQPSK / CCK
