Introduction
3
Package Contents
The following items should be included:
 WAP-6011 300Mbps N_Max Wireless Access Point
 Power Adapter
 Quick Start Guide
 CD-ROM containing the on-line manual and setup utility.
If any of the above items are damaged or missing, please contact your dealer immediately.
Physical Details
Front Panel LEDs
Figure 2: Front Panel
Security
Off - WPS feature is not in use.
On (White) - If the LED is on for a while and then off, WPS is processing
successfully.
Blinking (White) - WPS feature is currently in use.
WPS Button
Push the WPS button on the device and on your other wireless device to
perform WPS function that easily creates an encryption-secured wireless
connection automatically.
Wireless
On - Idle
Off - Wireless connection is not available.
LAN
On - The LAN port is active.
Off - No active connection on the LAN (Ethernet) port.
Power
On - Normal operation.
Off - No power
