Operation and Status
53
 Active - Connection exists
 Idle - No current connection, but no error has been detected.
This condition normally arises when an idle connection is au-
tomatically terminated.
 Failed - The connection was terminated abnormally. This
could be caused by Modem failure, or the loss of the connec-
tion to the ISP's server.
If there is an error, you can click the "Connection Details" button
to find out more information.
Internet IP Address
This IP Address is allocated by the ISP (Internet Service Provid-
er). If using a dynamic IP address, and no connection currently
exists, this information is unavailable.
WAN MAC Address
It displays the MAC address for the WAN.
Connection Details
Click this button to open a sub-window and view a detailed
description of the current connection. Depending on the type of
connection, a "log" may also be available.
LAN
IP Address
The IP Address of the Wireless ADSL Router.
Network Mask
The Network Mask (Subnet Mask) for the IP Address above.
DHCP Server
This shows the status of the DHCP Server function. The value
will be "Enabled" or "Disabled".
MAC Address
This shows the MAC Address for the Wireless ADSL Router, as
seen on the LAN interface.
Wireless
SSID 1
It displays the name of the SSID 1.
MAC Address
It displays the MAC address of the SSID 1.
SSID 2
It displays the name of the SSID 2.
MAC Address
It displays the MAC address of the SSID 2.
Region
The current region, as set on the Wireless screen.
Channel
This shows the Channel currently used, as set on the Wireless
screen.
Wireless AP
This indicates whether or not the Wireless Access Point feature is
enabled.
Broadcast Name
This indicates whether or not the SSID is Broadcast. This setting
is on the Wireless screen.
System
Device Name
The current name of the Router. This name is also the "hostname"
for users with an "@Home" type connection.
Firmware Version
The version of the current firmware installed.
Buttons
Connection Details
Click this button to open a sub-window and view a detailed
