LevelOne WBR-6601 - Connection Details - Fixed IP Address; Fixed IP Connection Information

Operation and Status
57
Connection Details - Fixed IP Address
If your access method is "Direct" (no login), with a fixed IP address, a screen like the following
example will be displayed when the "Connection Details" button is clicked.
Figure 50: Connection Details - Fixed/Dynamic IP Address
Data - Fixed IP address Screen
Internet
IP Address
The IP Address of this device, as seen by Internet users. This address
is allocated by your ISP (Internet Service Provider).
Network Mask
The Network Mask associated with the IP Address above.
Default Gateway
The IP Address of the remote Gateway or Router associated with the
IP Address above.
DNS Server
The IP Address of the Domain Name Server which is currently used.
