Work Area — Cabling
In-Wall Applications
Cat 6A cables require additional depth behind faceplates
and at all directional changes to maintain proper bend
radius. Before installation, verify that the design allows
sufficient depth throughout the cable pathway.
Drop Ceiling Applications
Cable infrastructure must be independently suspended by components
designed for this purpose, separate from all other building systems.
Do not use ductwork, piping, earthquake bracing, or the drop ceiling grid
to suspend cable or cabling support infrastructure.
Note: Hanger wire shown above is not part of the drop ceiling grid hanging system;
it was added later to independently hang the telecommunications infrastructure.
