Leviton Cat 6A - 5.6.5 - Multimedia Outlet System (MOS)

Multimedia Outlet System (MOS)
MOS OPTIONS
DESCRIPTION WHITE LT. ALMOND IVORY GREY BLACK STAINLESS
Wallplates
Single-Gang Wallplate 41290-SMW 41290-SMT 41290-SMI 41290-SMG 41290-SME 41290-SMS
Dual-Gang Wallplate 41290-DMW 41290-DMT 41290-DMI 41290-DMG 41290-DME 41290-DMS
Three-Gang Wallplate — — — — — 41290-TMS
AV Connector
Modules
VGA PC Module, 110-style termination, 1 unit high^ 41295-VPW 41295-VPT 41295-VPI 41295-VPG — —
VGA Monitor Module, 110-style termination, 1 unit high^ 41295-VMW 41295-VMT 41295-VMI 41295-VMG — —
HDMI Module, feedthrough, 1 unit high 41290-HDW 41290-HDT 41290-HDI 41290-HDG 41290-HDE —
Blank Modules
1-Port QuickPort Module (1 unit high) 41291-1MW 41291-1MT 41291-1MI 41291-1MG 41291-1ME —
2-Port QuickPort Module (1 unit high) 41291-2QW 41291-2QT 41291-2QI 41291-2QG 41291-2QE —
^ 110-Style VGA modules require both PC and Monitor modules used in pairs to operate.
MOS provides a clean and flexible system to integrate data and AV modules
into one wallplate or surface-mount box. Changes are made without removing
the wallplate from the wall, and all wiring and cabling is done from the front side
of the wallplate. The modules are available in 0.5, 1, 1.5 and 2 unit high sizes.
More options available: Visit Leviton.com/MOS for a full listing.
Single-Gang
Wallplate
Dual-Gang Wallplate
VGA PC Module HDMI Module
1-Port
QuickPort Module
2-Port
QuickPort Module
