GETTING STARTED
1.
Open the back cover of the air purifier
and remove both filters from their plastic
packaging. [Figure 1.1]
2. Place the Activated Carbon Filter back
into the air purifier, followed by the Fine
Preliminary/True HEPA Combination
Filter. Make sure the pull tabs on both
filters are facing out. [Figure 1.2]
3. Replace the back cover by lining up
the cover’s feet with the slots in the
bottom of the housing. Make sure that
the triangular piece at the bottom of
the cover is touching the safety switch.
[Figure 1.3]
4. Push the cover closed.
5. Place the air purifier on a hard,
flat surface. Leave 38 cm / 15 in of
clearance on all sides of the air purifier.
[Figure 1.4]
Note: Do not remove the foam
piece attached to the dust sensor
cover unless instructed by
Customer
Support
. [Figure 1.5]
Figure 1.1
Figure 1.4
Figure 1.5
Figure 1.2
Figure 1.3
Tabs facing
outward
38 cm /
15 in
Safety
switch
38 cm /
15 in
