Levoit LV-H133 Manual

10
1. Turn o and unplug the air filter, then remove the filter cover.
[Figure 4.1]
Replacing the Air Filter
2. Remove the old air filter and properly dispose of it.
[Figure 4.2]
3. (Optional) Clean any remaining dust and dirt from inside the
housing using a vacuum hose. [Figure 4.3]
4. Unwrap the new air filter and place it into the housing. Make
sure the black pull tabs are facing out. [Figure 4.4]
Figure 4.1
Figure 4.2
Figure 4.4
Figure 4.3
black tabs
facing out
unplug
air purifier
5. Replace the back cover onto the housing. [Figure 4.5]
6. Plug in and turn on the air purifier. Then press and hold for
3 seconds (see Resetting the Air Purifier, page 11).
NOTE:
• Do not clean the filter with water or other liquid.
• The back cover must be properly secured to the unit in order for it to
power on.
Figure 4.5

Levoit LV-H133 Specifications

General

Timer	Yes
Efficiency	99.97 %
Noise level	54 dB
Certification	CARB, FCC, ETL
Air purify rate	466 m³/h
Number of speeds	-
Noise level (low speed)	25 dB
Operating temperature (T-T)	-10 - 40 °C
Suitable for room area up to	41 m²
Operating relative humidity (H-H)	0 - 85 %
Particle filtration	0.3 µm
Filtering capability	Cigarette smoke, Fine dust, Pollen
Number of filter stages	3
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	45 W
Power consumption (standby)	0.8 W
Control type	Touch
Display type	LED
Product color	Black

Weight and Dimensions

Width	318 mm
Height	600 mm
Weight	9500 g
