Levoit LV-H133 Manual

6
GETTING STARTED
Figure 1.1
Figure 1.2
black tabs
facing out
1. Pull the handle of the filter cover to open the housing.
Remove the air filter from the housing. [Figure 1.1]
2. Take the filter out of its plastic packaging, then reinstall it into
the housing. Make sure the black pull tabs on the filter are
facing out. [Figure 1.2]
NOTE:
• If you are not planning to use the air purifier for a long period of time, we recommend leaving the filter inside
its plastic packaging until it is ready to be used. This helps prevent mold from building up on the air filter.
• If the filter cover is not properly installed, the air purifier will not turn on.
Figure 1.3
Figure 1.4
3. Replace the filter cover by aligning the bottom portion of the
cover with the inlets on the bottom of the housing. [Figure 1.3]
4. Once the bottom portion is properly aligned, slowly close the
cover by aligning its top part with the inlets at the top of the
opening. [Figure 1.4]

Levoit LV-H133 Specifications

General

Timer	Yes
Efficiency	99.97 %
Noise level	54 dB
Certification	CARB, FCC, ETL
Air purify rate	466 m³/h
Number of speeds	-
Noise level (low speed)	25 dB
Operating temperature (T-T)	-10 - 40 °C
Suitable for room area up to	41 m²
Operating relative humidity (H-H)	0 - 85 %
Particle filtration	0.3 µm
Filtering capability	Cigarette smoke, Fine dust, Pollen
Number of filter stages	3
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	45 W
Power consumption (standby)	0.8 W
Control type	Touch
Display type	LED
Product color	Black

Weight and Dimensions

Width	318 mm
Height	600 mm
Weight	9500 g
