Levoit LV-H133 Manual

7
About the Safety Trigger
Figure 2.1
When replacing the filter cover onto the air purifier, always make
sure the magnetic safety trigger is properly aligned with its
respective area. [Figure 2.1]
OPERATION
General Operation
1. Place the air purifier on a level surface. [Figure 3.1]
2. Plug the air purifier into a powered electrical outlet.
3. Tap to turn on the air purifier. It will start operating at
medium speed.
4. (Optional) Tap to adjust the fan speed of the air purifier.
There are 3 fan speeds to choose from (see Button Controls
& Functions, page 8).
5. Tap to turn o the air purifier when you are finished
using it.
NOTE: Always allow at least 15 inches (38 cm) of clearance on all sides
of the air purifier. [Figure 3.2]
Figure 3.1
Figure 3.2
NOTE: If the trigger is not properly aligned, the air
purifier will not turn on.
safety trigger makes
contact with the base
38 cm

Levoit LV-H133 Specifications

General

Timer	Yes
Efficiency	99.97 %
Noise level	54 dB
Certification	CARB, FCC, ETL
Air purify rate	466 m³/h
Number of speeds	-
Noise level (low speed)	25 dB
Operating temperature (T-T)	-10 - 40 °C
Suitable for room area up to	41 m²
Operating relative humidity (H-H)	0 - 85 %
Particle filtration	0.3 µm
Filtering capability	Cigarette smoke, Fine dust, Pollen
Number of filter stages	3
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	45 W
Power consumption (standby)	0.8 W
Control type	Touch
Display type	LED
Product color	Black

Weight and Dimensions

Width	318 mm
Height	600 mm
Weight	9500 g
