Levoit LV-H133 Manual

13
Problem Cause Solution
Poor air purification quality. Room is larger than the air purifier’s applicable
area.
Ensure the room is smaller than 538 ft
(50 m).
Air intake or outlet is blocked. Remove objects blocking air intake or outlet.
Filter is not properly placed inside the housing. Properly place the filter (see Getting Started
and Replacing the Air Filter, pages 6
and 10).
The air filter is dirty and cannot produce fresh air
anymore.
Replace the air filter (see Replacing the Air
Filter, page 10).
Not enough clearance on all sides of the purifier. Ensure there is at least 15 inches (38 cm) of
clearance on all sides of the purifier.
The air purifier is producing an
unpleasant odor.
The air filter is dirty and cannot produce fresh air
anymore.
Replace the air filter (see Replacing the Air
Filter, page 10).
High humidity levels have caused mildew to grow
on the air filters.
Replace the air filter, and move the air purifier
to a room where the relative humidity is less
than 85% RH.
is still illuminated after
replacing the air filter.
The air purifier has not been reset. Reset the unit (see Resetting the Air Purifier,
page 11).

Levoit LV-H133 Specifications

General

Timer	Yes
Efficiency	99.97 %
Noise level	54 dB
Certification	CARB, FCC, ETL
Air purify rate	466 m³/h
Number of speeds	-
Noise level (low speed)	25 dB
Operating temperature (T-T)	-10 - 40 °C
Suitable for room area up to	41 m²
Operating relative humidity (H-H)	0 - 85 %
Particle filtration	0.3 µm
Filtering capability	Cigarette smoke, Fine dust, Pollen
Number of filter stages	3
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	45 W
Power consumption (standby)	0.8 W
Control type	Touch
Display type	LED
Product color	Black

Weight and Dimensions

Width	318 mm
Height	600 mm
Weight	9500 g
