2-3
Front Panel Operation
ADJUST
Pitch Intervl HiCut LoCut
On Fifth 0 1.15Hz 1.35kHz
PchFine
Pitch Intervl HiCut LoCut
On Fifth 0 320Hz 1.35kHz
PchFine
1234567 1234567 1234567 1234567 1234567
1234567 1234567 1234567 1234567 1234567
The LXP-15 Display
On most of the LXP-15 display pages, three lines of alphanumeric information
are available:
1. System status
2. Parameter names
3. Parameter settings
The front panel VIEW button allows you to choose between display of the first
and second, or the second and third lines.
In this example pressing this button has
selected "HiCut". The value of this parameter is
bracketed by arrows to highlight its selection.
Turning the ADJUST knob alters the value
of the selected item.
allows you to alternate these displays.
In general, pressing the button below any display field will select the item in that
field for modification by the ADJUST knob.
Each display line is divided into five 7-character fields. This allows as many as
five items to be displayed simultaneously.
VIEW
This line shows system status
Params appear on this line
VIEW
Params appear on this line
Param values are shown here
Pressing VIEW
