Lexicon
LXP-15 Owner's Manual
4-14
Setting up Global
Patches
NOTE: The Udpate function on the “Sys” page is an aid to creating patches.
When Update is set to “On,” the displayed Destination and Offset values will
change as the Source controller is moved. This allows you to see the effect
of a Source on its Destination. The Update function affects the response time
of the LXP-15. Once you’ve got the patch set up the way you want, set
Update to “Off” for the fastest response during performance.
Global patches can be enabled/disabled from the front-panel of the LXP-15. To
do this, simply turn the PAGE knob to “Global.” The display will show:
Dest Source - - Mode
XX X
Pressing the button directly beneath “Mode” allows ADJUST to select: Off,
Delayed or Immed.
Off disables all global patches.
When Delayed is selected and a new setup is recalled, the Destination values
will remain at their initial settings until the assigned controllers are moved.
When Immed is selected and a new setup is recalled, the Destination values will
immediately change to the current value of the assigned controllers.
NOTE: Set the Source for all Destinations you don’t want to control globally
to “Off.” If the Destination is set to a Source not physically connected to the
LXP-15, its value will jump to minimum when in the Immediate mode.
The Delayed mode is the best choice for most applications because the inital
settings are retained until a control Source is moved.
Pressing the button immediately beneath Dest allows ADJUST to select any of
the Destinations shown in the Destination Parameters table on the previous
page. Destinations that are active in the algorithim of the current setup are
displayed with a text label (Pitch, Delay L, etc.). Inactive Destinations are
indicated by a number. As you scroll through the available Destinations, the
Source currently assigned to each Destination will also be displayed. To change
the Source assignment for any displayed Destination, press the button directly
beneath “Source.” ADJUST will now allow you to select any Source. Selecting
“Off” as a Source disables the Source assignment (i.e. there will be no global
patch assignment for the displayed Destination).
The relationship of Source position to Destination value is as follows for all Global
patches: As the Source is moved from its minimum position to its maximum
position, the Destination changes from its minimum value to its maximum value.
Mode
Dest and Source
