LXP-15 Owner's Manual
7-4
The Single Program and All User Data dump share the same format. The Single
Program dump sends all of the stored parameters for the selected setup; the All
User Data dump sends all 128 copies of the stored programs.
Data Byte # Data Param # Data Description
0-26 0-26 Microcode Parameters
27 27 General Purpose Patch 1 Source
28 28 General Purpose Patch 1 Threshold
29 29 General Purpose Patch 1 Destination
30,31 +30(31) General Purpose Patch 1 Scale
32,33 +32(33) General Purpose Patch 1 Offset
34-40 34-40 General Purpose Patch 2
41-47 41-47 General Purpose Patch 3
48-54 48-54 General Purpose Patch 4
55-66 55-66 Name (12 characters)
The Active Setup data dump sends all the parameters for the current setup as
well as the global parameters. The format is:
Data Byte # Data Param # Data Description
(Program parameters)
0-26 0-26 Microcode Parameters
27 27 General Purpose Patch 1 Source
28 28 General Purpose Patch 1 Threshold
29 29 General Purpose Patch 1 Destination
30,31 +30(31) General Purpose Patch 1 Scale
32,33 +32(33) General Purpose Patch 1 Offset
34-40 34-40 General Purpose Patch 2
41-47 41-47 General Purpose Patch 3
48-54 48-54 General Purpose Patch 4
55-66 55-66 Name (12 characters)
(System parameters)
67 67 Setup Increment
68 68 Setup Decrement
69 69 Display Contrast
70 70 Display Brightness
71-74 71-74 Reserved
75 75 Register Number
76 76 Preset Number
77,78 +77(78) Setup Number
79 79 MIDI Channel
80 80 Global Patch mode
81 81 Display Update
82 82 Memory Protect (nonzero=protected)
83-95 83-95 Reserved
96-124 96-124 Global Patch Sources
+ indicates a big parameter. There may be others in Microcode Parameters, depending on the
program. The number in parentheses is the coarse portion.
Data Dump Contents
Single Program and
All User Data Dump
Active Setup Dump
