Lexicon LXP-15 User Manual

The Algorithms
3-13
Chorus Delay
Parameter pages in
the Chorus Delay algorithm
DELAY
Delay1 - Delay2 Feedbk3 Delay3
0-794ms 0-1.04s -99% to +99% 0-1.04s
(8.19ms steps) (8.19ms steps) (8.19ms steps)
PITCH EQ
- - - Treble -
320Hz-11.6kHz,
Full
REVERB
- - - - Diffus
0-100%
LEVEL
InLevl Mix Wet Pan Dry Pan OutLevl
0-100% 0-100% 100%L-51%L, 100%R-51%R, 0-100%
Center, Center,
51%R-100%R 51%R-100%R
MODULATION
LFO Rat ChorRat - - -
.03Hz-4.84Hz 1-16
(16 steps)
To get some idea of the types of sounds and effects that can be created with the
Chorus Delay algorithm, be sure to listen to and experiment with presets built on
this algorithm. (See Chapter 5: The Presets.)
The Chorus Delay algorithm is a six voice chorus configured as three stereo
pairs. Delay 1 sets the base delay for all three pairs, Delay 2 and Delay 3 set an
additional delay offset for Chorus 2 and Chorus 3. Random chorusing of ±4ms
of all three pairs is controlled by Chorus Rate. The feedback loop around Chorus
1 and Chorus 3 provides positive and negative feedback for dramatic chorus and
flanging effects.
Chorus 3
Output
L
Input
L
Input
R
Mix
Output Level
Dry Pan
Wet Pan
Dry Pan
+
+
Mix
Output L
e
+
Diffusion,
Treble
Feedback 3
Delay 1
Chorus 1
Chorus 2
Delay 2
Delay 3
Input
Level
