Lexicon LXP-15 User Manual

Lexicon
LXP-15 Owner's Manual
3-6
To get some idea of the types of sounds and effects that can be created with
the Pitch/Delay algorithm, be sure to listen to and experiment with presets
built on this algorithm. (See Chapter 5: The Presets .)
The Pitch/Delay algorithm allows as many as six simultaneous effects in series:
long delay with infinite looping, pitch shift, EQ, stereo delay, reverb, and a
panner. Delay L can be fed back through the pitch shifter for cascade effects.
Pitch/Delay is very useful for creating complex layered effects for instruments
and vocals. For example, you can have filtered echoes, pitch shift chorusing,
enhanced stereo spread, and reverb, all at once.
A special feature of this algorithm is loop sampling. The Predelay can be used
as a loop sampler controlled by Predelay Feedback. Any Pitch/Delay setup can
use the loop sampling feature. (Check out presets 116 and 117.) Choose a length
for Predelay, and set Predelay Feedback to 100% to start recirculation and lock
out further input. To precisely cue the end of the loop, set the Mix control to 0%
and listen to the input. Once the loop is captured, experiment with changing
Predelay to shorten it, or Interval to change its pitch.
Pitch/Delay
Reverb
Mix
Predelay
Pitch
Shifter
EQ
Delay L
Delay R
Predelay Feedback
Reverb
Effect
Feedback
Output
L
Input
L
Input
R
Mix
Output Level
Dry Pan
Wet Pan
Dry Pan
+
+
Mix
Output
+
+
Input
Level
+
+
